Parts for Ge JCTP30SM2SS: 04 - Door Lock Parts

This oven door latch assembly secures the door and communicates lock status to the control. Replacing a worn or jammed latch restores safe door locking so bake and self-clean cycles can start and finish correctly.

• Locks and unlocks the oven door when engaged or commanded by the control
• Secures the door during the self-clean cycle for safety
• Helps resolve issues such as a door that won't lock or unlock, self-clean that won't start/finish, or a persistent "door locked" indicator
• Wear, binding, or internal failure can prevent proper latching

• Disconnect power at the breaker before servicing
• Access location varies by model; typically serviced from the top, rear, or control/console area—follow your model's service procedures
• Transfer any mounting hardware and reconnect wire harnesses one at a time
• After installation, verify smooth latch movement and door locking before running a cycle

This factory screw secures components within your appliance, keeping panels, brackets, and other parts tight and aligned. Replacing a missing or stripped screw helps eliminate rattles and restores a solid, properly mounted assembly.

• Fastens appliance components to frames, brackets, or cooktop/oven structures
• Replaces missing, rusted, or stripped hardware
• Helps address loose or rattling panels and misaligned trim
• Restores a secure fit after service or cleaning

• Disconnect power; if gas, shut off the gas supply. Allow the appliance to cool completely
• Match the screw to its original location and length for proper fit
• Use the correct driver; start threads by hand to avoid cross-threading
• Tighten snugly without overtightening to prevent stripping metal or plastic
