Parts for Ge ZSC1000KBB02: 01 - Door Parts

This replacement handle assembly restores a secure, easy-to-grip door pull on compatible refrigerators, improving door access and appearance without replacing the whole door. Designed to match factory fit and function for a clean, finished look. What it does:

• Provides a sturdy grip for opening and closing the refrigerator door
• Replaces cracked, broken, loose or worn handles that affect use or appearance
• Secures to the door with factory mounting points for a proper fit
• Restores original door operation and user confidence when opening

• Use basic hand tools; follow the refrigerator manufacturer's disassembly steps
• Turn off ice/water supply and move stored items out of the way before starting
• Keep fasteners and trim pieces organized during removal to ensure correct reassembly
• Do not overtighten mounting screws to avoid stripping threads or damaging trim

This pin hinge is the pivot pin used in appliance doors to support and guide smooth opening and closing, helping restore proper door alignment and operation. What it does:

• Provides a secure pivot point for the appliance door to open and close smoothly
• Restores correct door alignment and helps prevent sagging or uneven gaps
• Helps the door latch and seal properly to maintain normal appliance performance
• Works as a replacement for worn, bent, or broken hinge pins

• Disconnect power and remove any stored product from the door area before starting
• Use basic hand tools; support the door while removing and installing the hinge to prevent damage
• Inspect surrounding hinge components and replace if worn to ensure proper alignment
• Wear gloves and eye protection; follow the appliance manufacturer's service instructions

This control mounting panel secures the appliance control/console assembly, providing a stable mounting surface that helps keep buttons, switches, and electronics aligned for reliable operation and easier repairs. What it does:

• Provides a rigid mounting surface for the control/console assembly
• Keeps control board and user interface components properly aligned
• Helps prevent movement or vibration-related contact issues
• Common replacement for cracked, bent, or damaged control panels that misalign controls

• Disconnect power to the appliance before starting any repair
• Typically accessed by removing the console or outer panel; keep fasteners organized
• Handle the control board and connectors carefully to avoid damage

This installation hardware kit provides the mounting fasteners and brackets needed to secure the appliance during installation for a stable, code-compliant fit. Use it to complete new installs or replace missing hardware. What it does:

• Provides the mounting fasteners and brackets used to secure the appliance to surrounding cabinetry or floor
• Prevents shifting, tilting or excessive vibration after installation
• Enables proper alignment and stable operation following service or replacement
• Restores missing or damaged installation hardware so the appliance installs correctly

• Follow the appliance installation instructions and local codes; use only the fasteners supplied or specified by the manufacturer
• Disconnect power to the appliance before performing any installation or service that requires moving the unit
• Use appropriate tools and safety gear; some installations may require two people to safely position and secure the appliance
• If the appliance requires model-specific brackets or shims, confirm fit with the model's installation instructions before final installation

This replacement spring restores proper tension in the affected mechanism so levers, latches, or linkages move smoothly and return to position. A fresh spring helps eliminate sticky action and inconsistent feel in your cooking appliance.

• Provides the return force for a lever, latch, or linkage
• Helps maintain smooth, consistent engagement of moving parts
• A weakened or broken spring can cause sticking, loose action, or parts that don't return to rest
• Replacing the spring can resolve sluggish operation and intermittent function

• Disconnect power at the breaker or unplug the appliance before servicing
• Note the original spring's orientation and mounting points; take reference photos before removal
• Use needle-nose pliers for handling; avoid overstretching the coils and verify smooth movement before restoring power

This outer door trim / door frame replaces damaged or cracked refrigerator door trim to restore appearance and proper fit. It provides a finished edge around the door and helps keep the door liner secured for reliable operation. What it does:

• Replaces a cracked, bent, or cosmetically damaged outer door trim piece
• Secures and aligns the door liner and outer shell for correct door fit
• Helps prevent rubbing, rattling, and gaps that can contribute to cold-air loss
• Restores the door's finished look and proper edge sealing

• Disconnect power to the appliance before beginning any repair
• Remove door and handle(s) per manufacturer instructions to access trim fasteners
• Keep track of screws and clips; transfer any door gasket or insulation if required
• Test door alignment and seal after installation; do not overtighten fasteners
