Parts for Craftsman 917377042: Drive Control / Gear Case / Wheels Parts

This 12-circuit electrical connector joins wiring harness sections to restore secure signal and power paths so controls and components operate reliably. It's a direct-fit replacement used where a multi-pin plug is needed. What it does:

• Provides a secure 12-circuit connection between harnesses or to a control assembly
• Maintains proper power and signal routing for multiple circuits
• Common symptoms indicating replacement: intermittent power, unresponsive controls, or devices that fail to start
• Replaces worn, cracked, corroded, or damaged plug housings and terminals

• Disconnect all power before servicing to avoid shock or shorting circuits
• Inspect mating terminals and wiring for corrosion or damage; replace damaged wiring as needed
• Ensure connector is fully seated and any locking tab/clips are engaged for a secure fit
• Use basic hand tools; avoid bending terminals or forcing misaligned pins

This 90° connector (CV136) replaces a worn or damaged right-angle fluid/tubing connector to restore a secure, low-profile hose connection and stop leaks or flow interruptions. It fits the CV136 connector family and matches OEM shape. What it does

• Provides a right-angle connection for tubing or hose runs where space is limited
• Replaces cracked, leaking, or loose inlet/outlet connectors
• Helps restore reliable fluid flow and prevents pooling or drips near the joint
• Works where a compact 90° routing is required to avoid kinks

• One 90° connector (CV136)

• Turn off power and shut off water or fluid supply before replacing
• Inspect mating tubing and seals; replace any damaged clamps or O-rings as needed
• Hand-start fittings to avoid cross-threading, then snug with appropriate tool—do not overtighten
