Parts for HLTD500AGW: Drum Assy Parts

This is a replacement dryer drive belt that wraps around the drum to turn it during drying cycles, restoring proper drum rotation for even drying. Designed to fit specified GE laundry dryers that use this OEM part number. What it does:

• Wraps around the dryer drum and motor/idler to transmit motor power and rotate the drum
• Replaces a stretched, cracked, frayed, or broken belt that causes the drum not to tumble
• Stops slipping or intermittent rotation that can lengthen drying times or prevent tumbling
• Helps eliminate squealing or grinding noises caused by a failing belt rubbing on components

• One dryer drive belt

• Disconnect power to the dryer before starting any repair; follow lockout/tagout best practices
• Access the drum per your model's service instructions (top/front panel or rear panel removal may be required)
• Route the belt around the drum and over the idler pulley/motor shaft as shown in your service diagram; ensure proper belt alignment and tension before reassembly
• Inspect idler pulley, rollers, and drum glides for wear while the dryer is open; replace if worn to prevent premature belt failure

Support A is a small mounting bracket that secures internal components and keeps assemblies aligned so your appliance operates quietly and reliably. It stabilizes parts to reduce vibration and prevent misalignment that can cause noise or wear. What it does:

• Provides structural support and secures internal assemblies or panels
• Helps keep components aligned to prevent rubbing, rattling, or uneven operation
• Reduces vibration and movement during normal use
• Can help stop intermittent noises or loose-feeling parts related to a failed or missing support

• Disconnect power (unplug appliance or switch off breaker) before service
• Access may require removing outer panels or trim — keep fasteners organized for reassembly
• Use basic hand tools; avoid forcing clips or fasteners to prevent damage
