This part is discontinued by the manufacturer and is no longer available for purchase.
This is a magneto armature, also known as an ignition coil. It consists of a large rubber housing with an aluminum mounting armature and an electrical lead cable. An ignition coil is an electronic part that converts low-voltage power from an engine flywheel to high-voltage power for a spark plug. When the ignition coil has failed, the motor will not start. Early signs of failure include motor stalling, especially at lower speeds. These can also be symptoms of a dirty carburetor, so that should also be checked. To test an ignition coil, disconnect it from everything except the spark plug, then disconnect the spark plug boot. Insert a multimeter inside the boot, with the other contact on the metal coil housing. If it reads between 2,500 and 5,000 ohms, the ignition coil is working. If it shows an infinity or 1, the coil has failed. This is an OEM part sourced directly from the manufacturer, and it is sold individually. Designed for Briggs & Stratton motors, it has also been used on Toro machines and replaces older part numbers 492341, 495859, and 491312.
Usually ships within 4 - 14 days
An ignition key set is used with a variety of lawn and garden equipment. When it's turned in the ignition slot, it will start the lawnmower, pressure washer, or other equipment. This set comes with two keys and a keyring to make it less likely that one will be lost. Ignition keys sometimes become damaged or broken and some people lose them, which means a replacement set is required.If a set of keys is lost or has been damaged, a new set will be needed to operate a lawnmower or other equipment. There is no installation process involved, so there's no need for additional tools. Once the replacement ignition key set is acquired, it can be used to get equipment back up and running. Simply turn the key to engage the motor and the lawn equipment will be ready to use.This ignition key set is designed for use with lawnmowers, wood chippers, snowblowers, generators, tillers, and pressure washers. It is compatible with equipment from Briggs & Stratton, Simplicity, Craftsman, Snapper, Cub Cadet, and Murray. This is a genuine OEM replacement part that comes as an individual component that consists of two silver keys on a ring.
