Parts for Thermador T24BR70FS-03: Frames Parts

This active carbon filter refreshes the air when your range hood is set to recirculate. Replace a saturated filter to restore effective odor reduction and maintain a more comfortable cooking space. What it does:

• Adsorbs cooking odors in recirculating operation
• Helps maintain fresher indoor air when venting back into the room
• Restores odor-removal performance when the old filter is saturated
• Typical signs it's time to replace: persistent cooking smells or diminished odor reduction

• One activated carbon filter

• Disconnect power to the hood before servicing
• Remove the metal grease filter(s) to access the charcoal filter
• Release the old filter from its clips/bayonet mount and install the new filter in the same orientation until it locks
• Charcoal filters are not washable; replace when saturated

• For hoods configured for recirculation; not used when vented to the outdoors

Replacement retaining pin that secures appliance components so panels, hinges or linkages stay connected. Use this direct-fit hardware to restore proper alignment and reduce looseness, rattling or separation caused by a missing, bent or worn pin.

• Secures mating parts like hinges, levers or shafts to prevent separation and play
• Common symptom: loose or rattling door/panel or misaligned assembly where the original pin is missing or damaged
• Typical use: keeps pivot points and small assemblies aligned for proper operation
• Metal fastener designed for a simple, local replacement

• Disconnect power (and water, if appliance type requires) before servicing
• Remove any obstructions and note original orientation before removing the old pin
• Use appropriate hand tools; do not force parts—if fit is tight, inspect mating components for damage

This profile stripe is a decorative trim piece that restores the finished look of a PROFILE-series appliance door and helps protect the exposed edge from wear. It matches the appliance profile to keep the door looking complete and aligned. What it does:

• Covers the exposed door edge or seam to restore original appearance
• Protects the door edge from chips, scuffs and daily wear
• Hides mounting holes and fasteners for a clean, finished look
• Helps maintain the aesthetic alignment between door panels and handle area

• High-level replacement — typically snaps or slides into place; check for exact steps
• Use care to avoid scratching adjacent surfaces during installation
• Disconnect power or follow manufacturer safety guidance if working near electrical components
• If adhesive is used, allow recommended cure time before closing or using the door
