Parts for Ge GSA20IBPHFBB: 01 - Freezer Door Parts

This dart clip is a small plastic retainer that secures wiring, tubing or trim inside your appliance to prevent rubbing and movement. It helps keep internal components in the correct position for reliable operation and reduced vibration. What it does:

• Secures wiring, harnesses or small tubing to chassis or panels to prevent abrasion
• Keeps trim and lightweight panels held in place to reduce rattling and noise
• Prevents loose components that can interfere with moving parts
• Common symptom of a failed clip: loose wires, rubbing noises or panels that don't stay aligned

• Disconnect power to the appliance before servicing to avoid shock or injury
• Access may require removing panels or trim; keep fasteners organized for reassembly
• Replace only the damaged clips; push-fit design usually snaps into place by hand or with pliers
• If routing or securing wiring, ensure wires are not pinched and have proper clearance from moving or hot parts

This freezer door stop plate helps position and secure the door by limiting its swing, restoring proper alignment and preventing over-rotation that can cause gaps or rubbing. Simple replacement for worn or damaged stops. What it does:

• Stops the freezer door at the correct open/closed position so the door seals properly
• Prevents the door from swinging too far and rubbing or catching on the cabinet
• Restores consistent door alignment when the original stop is bent, broken, or missing
• Reduces wear on hinge and gasket areas caused by improper door travel

• One freezer door stop plate

• Disconnect power to the appliance before starting any repair to avoid injury
• Remove the freezer door or access panel as needed to reach the stop plate
• Use hand tools to remove/install mounting screws; align the plate before tightening to avoid misalignment
• Do not force parts; if mounting holes are damaged, assess bracket/hinge condition before finalizing repair

This freezer door gasket creates an airtight seal around the door to keep cold air in and moisture out. Replacing a worn seal helps restore stable temperatures, reduce frost and condensation, and improve overall efficiency. What it does:

• Seals the perimeter of the freezer door to prevent air leaks and humidity intrusion
• Helps maintain consistent internal temperature and energy performance
• Replaces gaskets that are torn, warped, brittle, or won't stay seated
• Common symptoms include excess frost or ice near the door, condensation around the frame, or the door not closing flush

• 1 freezer door gasket

• Disconnect power before servicing
• Warm the new gasket in hot water or with a low-heat hair dryer to improve flexibility
• Remove the old gasket and press the new gasket fully into the door channel, starting at the corners
• Close the door and check for an even seal (use a "dollar bill" test); allow up to 24 hours for the gasket to relax and conform

This tail handle is the replacement tail piece for a refrigerator door handle assembly, restoring a secure grip and proper door operation. It helps refresh worn or broken handle ends without replacing the full handle assembly. What it does:

• Replaces a damaged or cracked tail piece on the refrigerator door handle
• Restores a solid grip and proper alignment of the handle
• Helps stop rattling or looseness caused by a broken tail section
• Useful when the main handle is intact but the tail end is worn or broken

• One tail handle tail piece

• Basic hand tools typically required; handle with care to avoid scratching door finish
• Keep power off/unplug appliance only if working near electrical components or lights
• If fasteners or clips are missing, replace with OEM-specified hardware

This is a screw intended for use in refrigerators, specifically as the top mounting screw for the handle. If the screw in the handle is missing, stripped, or otherwise not performing its function, a replacement screw should be ordered.A visual inspection will determine if a screw is missing. If the door handle is loose or falling off from the top, it is a sign that a replacement screw is required. This repair is a quick and easy process. It involves the use of a screwdriver. Remove the old screw if there is one in place. Line up the holes on the door and the door handle component before twisting the new screw into position. Wear gloves to protect hands during the repair.This screw is a genuine OEM replacement part. It is sourced directly from the manufacturer. The screw is sold individually. The screw is compatible with several different models of refrigerators. It can be installed in ranges made by Electrolux, Frigidaire, Gibson, Westinghouse, and Kelvinator.

10-32 F HXW 3/4 S

This kit is required when replacing the freezer door. For the freezer door order by model number.

This top-closed thimble is a small protective plug that presses into a cabinet opening to cap and finish the hole, helping prevent abrasion and limiting air or moisture leaks for reliable appliance performance.

• Caps and seals an unused hole/opening in the liner or cabinet
• Shields edges to help protect nearby wiring or tubing from chafing
• Helps reduce drafts and moisture migration that can contribute to frost, condensation, or temperature swings
• Replace if cracked, brittle, loose, missing, or if you notice gaps or rubbing noises

• Disconnect power; if applicable, turn off the water supply
• Access the opening, remove the old thimble/plug, and clean the area
• Align and press the new thimble into the hole until fully seated and flush; avoid pinching wires or tubing
• Restore power/water and verify a snug fit
