Product Details
Genuine Frigidaire part. Frigidaire brands include Electrolux, Frigidaire, Gibson, Kelvinator, Westinghouse, Kenmore, and others.
See all items in Refrigerator Lever.
Electrolux also makes various appliance models for Sears / Kenmore
Cross Reference Information
Part Number 241973501 replaces AP4450570, 242156901, 1531479, 7241973501, AH2368179, EA2368179, PS2368179.
Description
This dispenser actuator is a small internal lever in the refrigerator's door dispenser. It engages the switch/mechanism when you press the paddle, helping restore reliable ice or water dispensing and a firm, responsive feel at the dispenser.
- Transfers dispenser paddle movement to the ice/water switch
- If cracked or worn, ice or water may not dispense when pressed
- Dispenser paddle may feel loose, stick, or require extra force
- Can cause intermittent response at the dispenser
What's included: 1 actuator Installation notes:
- Unplug the refrigerator and shut off the water supply before servicing
- Remove the dispenser trim/escutcheon and panel as directed by your model's instructions
- Replace the actuator, ensuring proper alignment with the switch and pivot points
- Reassemble, restore power, and test both ice and water dispensing
