Randall P Shepherdsville , KY December 11, 2015 Bake element wasn't heating up when turned on Turned stove breaker off in the main breaker box and also unplugged the oven from the 220 outlet. pulled the baking racks out of the oven and proceeded to locate the 1/4 screws just above the bake element where it passes through the metal wall and removed them. pulled the element forward until the wires were exposed and unplugged them and then attached the new element to the wires and reinstalled in reverse order. Read More... 2 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: Less than 15 minutes Tools: Nut Drivers
Dorothy D Lawrenceville , GA March 29, 2015 Appliance: Model KENMORE FLAT TOP My bake element burned out i fixed it by I fixed it by buying a new bake element Read More... 1 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: Less than 15 minutes Tools: Nut Drivers
Richard B Liberty Hill , TX October 20, 2016 Appliance: Model KENMORE 7909612408 The baking element and the broil element went dead suddenly & at the same time This is on a 10 year old, all electric Kenmore (aka Frigidaire). Internet search for my oven lead to checking control panel. Voltage in but not out at either element.. Further Googling, indicated control panel likely culprit. R&R control panel brought broil element to life & voltage out for baking (at the CP) but no heat at the baking element. Infinite resistance thru the suspect element and 40ish ohms thru the working element. R&R baking heat element with a part from AppliancePartsPros and everything works again. $200 total parts. 30 minutes total work time but lots of hurry up & wait time. I had a half-vast wiring diagram and prior knowledge of using a VOM Read More... 1 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: 15-30 minutes Tools: Nut Drivers, Screwdrivers
Dan M Westfield , IN January 02, 2016 Appliance: Kenmore Electric Range 7909611340A Oven taking very long to get up Replaced both elements. Very simple -- until one of the connection wires slipped back through the hole after disconnecting from the element! Had to take the back cover off the range to get to it. Still not a bad job, only half dozen screws. Read More... 1 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: Less than 15 minutes Tools: Nut Drivers
Charles R Caliente , NV March 13, 2022 Appliance: Kenmore Electric Range 79096122406 Bake element on electric range shorted out. Unscrewed element on each side, cleaned contacts with spray contact cleaner and reconnected. Read More... Do-It-Yourself Rating: Repair Time Estimate: 15-30 minutes Tools: Screwdrivers
