Frigidaire 241829001 Auger Drive Bar (Ice Dispenser) OEM Part

Product Details

Genuine Frigidaire part. Frigidaire brands include Electrolux, Frigidaire, Gibson, Kelvinator, Westinghouse, Kenmore, and others. See all items in Refrigerator Auger, Helix, Crusher, Refrigerator Ice Maker & Related and Refrigerator Shaft Or Pin.
Electrolux also makes various appliance models for Sears / Kenmore

Cross Reference Information

Part Number 241829001 replaces AP4451224, 1531390, 7241829001, AH2368085, EA2368085, PS2368085.

Description

This auger drive bar links the dispenser motor to the ice bucket auger, transmitting torque to move cubes or crushed ice to the chute. Replacing a worn or stripped bar restores consistent, reliable ice dispensing. What it does:

• Couples the dispenser motor to the auger/crusher assembly
• Transfers rotation so ice advances to the dispenser chute
• Interfaces with the cube/crush selector mechanism
• Common symptoms include the motor running but no ice dispensing, intermittent dispensing, the auger not turning, or grinding/clicking from the dispenser

What's included:

• 1 auger drive bar

Install notes:

• Disconnect power and remove the ice bucket before servicing
• Note the bar's orientation; remove any retainers and separate it from the yoke/coupler
• Align the new bar with the mating parts and seat it fully; transfer any reusable retainers
• Reinstall the bin and test both cube and crush selections
