Frigidaire 318185336 Clock/Timer (Electronic Oven Control) OEM Part

Product Details

Genuine Frigidaire part. Frigidaire brands include Electrolux, Frigidaire, Gibson, Kelvinator, Westinghouse, Kenmore, and others. See all items in Range / Cooktop / Oven Control Board.
Electrolux also makes various appliance models for Sears / Kenmore

Cross Reference Information

Part Number 318185336 replaces AP3963585, 1197497, 318185320, AH1528735, EA1528735, PS1528735.

Description

This is the electronic clock/timer that controls the oven's timekeeping, display, and cooking functions. A failing control can stop bake or broil from working and make the display or keypad unresponsive.

• Governs oven functions such as bake/broil through internal relays
• Provides the time display, kitchen timer, and programmable settings
• Faulty unit can cause no heat, dead or dim display, unresponsive buttons, or error codes
• Intermittent beeping or failure to start/stop cycles can also indicate a bad control

What's included: One clock/timer electronic control assembly. Install notes:

• Disconnect power at the breaker before servicing—high voltage present
• Take a photo of wire locations; transfer connectors one at a time to the new control
• Handle the board carefully and avoid static discharge; do not touch relay contacts
• After installation, restore power and set the clock before testing oven functions
