Frigidaire 316576621 Electronic Oven Control Board (Clock/Timer) OEM Part

Product Details

Genuine Frigidaire part. Frigidaire brands include Electrolux, Frigidaire, Gibson, Kelvinator, Westinghouse, Kenmore, and others. See all items in Range / Cooktop / Oven Control Board.
Electrolux also makes various appliance models for Sears / Kenmore

Cross Reference Information

Part Number 316576621 replaces AP4508087, 1565019, 316516521, 316516531, 316516536, 7316516536, 7316576621, 903139-9030, 903139-9040, 903139-9090, 903146-9010, 903150-9010, AH2378975, EA2378975, PS2378975.

Description

This electronic oven control board governs the oven's heating functions and provides the digital clock/timer display. Replacing a failed EOC restores accurate temperature control and responsive keypad functions for reliable baking and broiling. What it does:

• Regulates bake, broil, and clean cycles by switching power to the heating circuits based on sensor feedback
• Runs the user interface, including the clock, timer, and status display
• Interprets keypad/overlay inputs and commands the oven relays
• Addresses symptoms like a blank or dim display, unresponsive buttons, oven not starting/heating, erratic temperatures, or an error shown on the display

What's included:

• 1 electronic oven control board (EOC)

Install notes:

• Disconnect power at the breaker and let the appliance cool before servicing
• Use ESD precautions; handle the board by the edges
• Photograph wiring and transfer connectors one at a time to the new board
• Reuse existing mounting hardware and ensure all ribbon/plug connections are fully seated before restoring power
