Frigidaire 216714601 Temperature Control (Thermostat) OEM Part

Product Details

Genuine Frigidaire part. Frigidaire brands include Electrolux, Frigidaire, Gibson, Kelvinator, Westinghouse, Kenmore, and others. See all items in Freezer Temperature Control, Cold Control and Refrigerator Temperature Control, Cold Control.
Electrolux also makes various appliance models for Sears / Kenmore

Cross Reference Information

Part Number 216714601 replaces AP3214435, 941918, AH735556, EA735556, PS735556.

Description

This temperature control thermostat regulates cabinet temperature by cycling the cooling system on and off. It helps your appliance hold the setting you select so food stays cold without unnecessary overcooling.

• Senses internal temperature and opens/closes electrical contacts to start or stop the compressor
• Maintains the setpoint chosen with the control knob
• Symptoms of a failing control include: too warm or too cold temperatures
• Runs constantly or won't run unless tapped/adjusted
• Temperature knob has little or no effect on cooling

What's included: 1 temperature control thermostat Install notes:

• Disconnect power before servicing
• Note wire locations and take photos before removal
• Route the sensing capillary/bulb exactly as original; do not kink or sharply bend it
• Secure the sensing bulb in its clips and ensure good contact; set to mid-range and allow up to 24 hours for temperatures to stabilize
