Kent S Springfield , OH October 24, 2020 Appliance: Model FRIGIDAIRE MFU17F3GW6 Freezer was shuuting down or not coming back on after defrost cycle I replaced defrost timer (which I am glad I did because of wear on the points) but that did not cure the problem. So after checking other components, I found that the temperature control was the culprit. No problem, I will simply order part # 2162521100. Well Frigidaire decided to obsolete that part and "Has not provided an approved substitute". So, I have to scrap this freezer and pay $800 to $900 for a new one? Not! So I kept looking at subsequent freezer temperature controls and found part # 216788000. I also purchased part # 216707200, control knob, because looking at the pictures and comparing the old switch to the new, it was obvious the old knob would not work on the updated switch. I intended to replace the old front mount bracket onto the new switch but decided I didn't need to do that. I simply mounted the new switch at 90 degrees angle and glued it so that it would not slide back and forth in the current cutout of the back panel. Then, I properly mounted the Styrofoam vapor box surrounding the switch. Frigidaire originally had it mounted with plumber's putty and it was loose when I removed the panel. Dumb application on their part which probably help cause the original problem. This repair was made about six weeks ago and so far the old freezer works as well as the day it was delivered. Read More... 8 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: 1-2 hours Tools: Nut Drivers, Pliers, Screwdrivers
Harold B Wheatfield , IN August 04, 2015 Appliance: Model 253.011011 Freezer running all the time but not cooling Change the temperature control unit Read More... 5 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: 15-30 minutes Tools: Screwdrivers
John P Silverdale , WA November 26, 2020 My freezer would not stay cold I figured out what I needed, ordered my parts and then two days had them in my hand. They were the correct parts and I had no problem installing them. Within an hour my freezer was up and running and now I can go back to hoarding food, ha ha. Read More... 1 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: 1-2 hours Tools: Screwdrivers
Tommy H Hayesville , NC June 11, 2022 The compressor ran all the time! Purchased both defrost thermostat and temperature control and replaced both fixed it perfectly. It was not exactly the same as the old one, did a little engineering, didn’t come with a knob but had it set by using a thermometer ?? Thanks, you all do good!! Read More... 1 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: 15-30 minutes
Anthony C Huntington , NY September 14, 2021 Inconsistent temperature freezing coil. Replaced 3 items T Stat , Defrost Timer & Coil Stat Compressor was operating normal Total cost + - $160.00 Alternative ===New Freezer @ $700.00 FREEZER WORKING WELL Read More... Do-It-Yourself Rating: Repair Time Estimate: 30-60 minutes Tools: Pliers, Screwdrivers
