Frigidaire 316560147 Oven Control Board (Electronic Clock/Timer) OEM Part

Product Details

Genuine Frigidaire part. Frigidaire brands include Electrolux, Frigidaire, Gibson, Kelvinator, Westinghouse, Kenmore, and others. See all items in Range / Cooktop / Oven Control Board.
Electrolux also makes various appliance models for Sears / Kenmore

Cross Reference Information

Part Number 316560147 replaces AP4499711, 1553927, AH2373544, EA2373544, PS2373544.

Description

This electronic oven control board governs the appliance's heating and front-panel functions. Replacing a failed board can restore accurate temperature control, mode selection, and display/timer operation.

• Controls bake and broil relays to reach and maintain the set temperature
• Manages the oven clock, timer, and digital display
• Receives keypad inputs for mode and temperature selection
• Monitors the temperature sensor and can register fault codes
• Common symptoms: oven won't heat or start, blank/erratic display, unresponsive buttons, random beeps or error codes

What's included: 1 electronic control board Installation notes:

• Disconnect power at the breaker before servicing
• Use ESD precautions; avoid touching circuitry and contacts
• Label or photograph all wiring; transfer mounting hardware and the existing faceplate/overlay if applicable
• After installation, run a test cycle; some models may require initialization or calibration per the service sheet in the unit
