Frigidaire 5304509479 Diode (High-Voltage) OEM Part

Product Details

Genuine Frigidaire part. Frigidaire brands include Electrolux, Frigidaire, Gibson, Kelvinator, Westinghouse, Kenmore, and others. See all items in Microwave Diode Or Rectifier.
Electrolux also makes various appliance models for Sears / Kenmore

Cross Reference Information

Part Number 5304509479 replaces AP6230626, 5304464254, 5304472472, 4547235, PS12071314.

Description

This high-voltage diode rectifies AC to DC in the microwave's high-voltage circuit so the magnetron can generate heat. When it fails, the oven may run normally but won't heat or may blow fuses.

• Converts high-voltage AC to DC for magnetron operation
• Maintains correct polarity and protects the HV circuit
• Common failure symptoms: runs but no heat, loud hum then shutdown, blown internal fuse, or tripping breaker
• Visible burn or damage on the diode or leads may be present

What's included: 1 high-voltage diode

• Disconnect power before servicing; high voltage is present even when unplugged
• Safely discharge the high-voltage capacitor before touching HV components
• Match orientation to the original—polarity matters; ensure tight, insulated connections
