Frigidaire 137551800 Dispenser Drawer Housing OEM Part

Product Details

Genuine Frigidaire part. Frigidaire brands include Electrolux, Frigidaire, Gibson, Kelvinator, Westinghouse, Kenmore, and others. See all items in Washer Dryer Combo Blower Wheel Or Fan Blade.
Electrolux also makes various appliance models for Sears / Kenmore

Cross Reference Information

Part Number 137551800 replaces AP5691646, 134608200, 137134100, 3015869, PS8689122.

Description

This replacement housing is the body that holds the washer's detergent drawer and channels rinse water through each compartment into the tub. Replacing a cracked or warped housing restores proper dispensing and helps prevent leaks at the dispenser area.

• Supports and aligns the detergent/bleach/softener drawer
• Routes incoming water to flush each compartment into the wash tub
• Interfaces with inlet hoses and outlet chute for proper flow
• Common symptoms: water leaking from the dispenser/front panel, detergent or softener left in the drawer, poor dispensing, drawer difficult to open/close

What's included: One dispenser housing Install notes:

• Disconnect power and shut off water supply before servicing
• Remove necessary panels/trim, pull out the drawer, and release mounting screws/clips to access the housing
• Label and disconnect hoses; note routing. Transfer any reusable siphon caps, seals, and the drawer from the original housing
• Reassemble, restore water and power, and run a test fill to check for leaks
