Frigidaire 316430502 Ignitor Orifice Assembly (Surface Burner, Single) OEM Part

Product Details

Genuine Frigidaire part. Frigidaire brands include Electrolux, Frigidaire, Gibson, Kelvinator, Westinghouse, Kenmore, and others. See all items in Range / Cooktop / Oven Gas Conv Kit.
Electrolux also makes various appliance models for Sears / Kenmore

Cross Reference Information

Part Number 316430502 replaces AP3963542, 1197074, AH1528102, EA1528102, PS1528102.

Description

This ignitor orifice assembly positions the spark igniter and meters gas to a surface burner so the burner lights reliably. Replacing a damaged or clogged assembly helps restore consistent ignition and proper flame performance. What it does:

• Directs gas through the orifice and correctly locates the igniter for dependable spark ignition.
• Replaces corroded, clogged, or physically damaged orifice components that can block gas flow.
• Common symptoms it can fix: burner won't light, continuous clicking without ignition, weak or uneven flame.
• Restores consistent burner ignition and safer operation when the original assembly is compromised.

What's included: One ignitor orifice assembly. Install notes:

• Always disconnect power to the appliance and shut off the gas supply before starting work.
• Remove burner grate/cap as needed and replace the assembly in the original orientation; ensure the igniter is positioned correctly relative to the orifice.
• After installation, restore gas and power and check for proper ignition and any gas leaks; if you detect a gas odor or a persistent leak, stop.
• When in doubt or if access is difficult, check the appliance's service manual.
