Frigidaire 316536610 Ignitor Orifice Assembly (Surface Burner) OEM Part

Product Details

Genuine Frigidaire part. Frigidaire brands include Electrolux, Frigidaire, Gibson, Kelvinator, Westinghouse, Kenmore, and others. See all items in Range / Cooktop / Oven Burner & Related and Range / Cooktop / Oven Gas Conv Kit.
Electrolux also makes various appliance models for Sears / Kenmore

Cross Reference Information

Part Number 316536610 replaces AP4365801, 1484299, 316449500, AH2345283, EA2345283, PS2345283.

Description

This surface burner ignitor/orifice assembly directs gas through a calibrated orifice and provides the spark to ignite it. Replacing a worn or damaged assembly restores consistent lighting and an even flame on the affected rangetop burner.

• Routes gas from the valve through the orifice to the burner head
• Positions the ignitor for reliable sparking and quick ignition
• Helps maintain correct flame size and pattern on that burner
• Common symptoms: burner won't light, clicks without flame, delayed ignition, weak or uneven flame

What's included: One ignitor/orifice assembly. Install notes:

• Disconnect power and shut off the gas supply before servicing
• Remove grates, caps, and burner heads; lift the cooktop to access the assemblies
• Note wire routing and original orifice location; transfer any reusable hardware from the old part
• After installation, restore gas and check connections for leaks, then test spark and flame

Also known as: Orifice holder with ignitor; surface burner igniter/orifice assembly.
