Frigidaire 316406602 Insulation (Thermal), 1 Piece OEM Part

Product Details

Genuine Frigidaire part. Frigidaire brands include Electrolux, Frigidaire, Gibson, Kelvinator, Westinghouse, Kenmore, and others. See all items in Range / Cooktop / Oven Insulation, Sound Dampening.
Electrolux also makes various appliance models for Sears / Kenmore

Cross Reference Information

Part Number 316406602 replaces AP4357839, 1465798, AH2339215, EA2339215, PS2339215.

Description

This thermal insulation replaces the heat-retaining blanket used around the oven cabinet. Restoring the insulation helps the appliance maintain temperature and protects surrounding components and cabinetry from excessive heat. What it does:

• Reduces heat loss from the oven cavity to improve temperature stability
• Helps the unit preheat and recover more efficiently
• Limits heat transfer to side panels and the control area
• Reduces persistent burning odors if old insulation was contaminated by spills

What's included:

• 1 insulation piece

Install notes:

• Disconnect power and allow the appliance to cool completely before service
• If applicable, shut off gas supply before moving a range
• Wear gloves, long sleeves, and eye protection; fiberglass can irritate skin and eyes
• Note factory placement before removal; handle gently to maintain loft, avoid compressing, and ensure no wires are pinched when reassembling
