Eugenia Kay T Lexington , KY January 01, 2019 Appliance: Frigidaire Electric Range GLEF378ABC My Frigidaire stove just over heated and wouldn’t turn off. I had to unplug from outlet the display was flashing code f1. I went to the Appliance Parts Pros website and spoke with Shawn in customer service via the chat option. He was very helpful and suggested I order the thermostat for my stove. It arrived in about a week and I installed it the same day. It was a very easy install with the exception of the wiring harnesses didn’t match so I had to splice the wires together. It worked perfectly and now my stove is working like new. I really appreciate everything Shawn did to assist me and make this project much easier. Read More... 14 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: 30-60 minutes Tools: Pliers, Screwdrivers
John S Scranton , PA December 25, 2015 Appliance: Model KENMORE ELECTRIC RANGE My oven and broiler did not work but my stovetop did also i heard a loud pop when the oven and and broiler stopped working I bought a new clock assembly Read More... 5 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: Less than 15 minutes Tools: Socket Set
Carl B Bardstown , KY August 21, 2018 Oven made a popping sound then gave an Ff1 error code. I reset everything and still showed an F1 error code Researched the code, I read the instructions on the back of the oven, removed the OCB board, got online to shop around for a new one, got the best price from Appliance Parts Pro, Ordered it that evening, arrived next day.. Less than 10 minute fix .. Read More... 4 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: Less than 15 minutes Tools: Nut Drivers
Dennis B Costa Mesa , CA December 01, 2018 Appliance: Frigidaire Gas Range FGF366CCD Digital control panel Replaced the panel with the parts I ordered. This is the second time I have replaced the digital panel for my gas stove now 14 years old. Read More... 1 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: 30-60 minutes Tools: Nut Drivers
Roger A Valencia , PA December 07, 2018 Appliance: Model FRIGIDAIRE FEFL77ABA F1 error code Unscrewed the top back plate with a small nut driver and removed the controller with a phillips screwdriver (I used a 6-in-one for both). I replaced both the controller (AP3693959) and faceplate (AP2126499) at the same time rather than try to peel off the old faceplate. Before purchase, I was concerned my oven's 15 pin connector would not match the two 6 pin connectors on the controller. Here's how it goes: Plug the large 15 pin connector in matching up the first pin on the far left of the left 6 pin connector and it spans across both 6 pin connectors and works fine. There are three unused pins in the 15 pin connector at pin numbers 7, 14, and 15 (counting from the left). Pin 7 spans the bridge between the two 6 pin connectors and pins 14 and 15 extend beyond the right side of the right 6 pin connector. Take a picture of the old one before removal if you need to. Also, there are two unused spade terminals below the Bake-Broil-L1 spade terminals that do not get used on the new board. Hopefully, this new controller is more robust and does not fail in the FULL-ON condition as did the original board! Read More... Do-It-Yourself Rating: Repair Time Estimate: Less than 15 minutes Tools: Nut Drivers, Screwdrivers
