Frigidaire 316419303 Range Touch Pad Overlay OEM Part

Tried to replace the temperature probe first without testing with ohm meter; decided to take a chance. I then ordered the EOC timer/oven control. Now works great and also gained the seconds timer along with minute timer that was not stock with the first timer. Happy man; didn't have to pay the labor to install the parts, the videos gave me the confidence that I could complete the repair.

Bought the recommended replacement part, reviewed the repair video provided by Appliance Parts Pro, then replaced the failed control panel. Worked great.

Unplugged stove and took off back panel. Removed old overlay with a knife and clean off glue. Remove four screws and install new overlay. Put everything back. Less than a hour easy job I am seventh three years old.

Replaced the control board, control board overlay and the indicator lens using a phillips screw driver, 1/4" nut driver and a pair of needle nose pliers. Took all of 15 minutes.

My oven was overheating and generating an F10 error code. I discovered that a new clock/timer unit was a likely fix. The old clock/timer unit overlay was cracked and peeling off so I figured I'd address both issues simultaneously. I removed the back of the range, unscrewed and pulled out the old clock/timer unit. I then applied the overlay (it has a sticky back) to the new clock/timer unit and mounted it into the range. This was a simple case of plugging in a couple of strip connectors and a few control wires. In total, it took about 15 min (I spent longer moving the range away from the wall and trying to get it back in place again than I did doing the repair).
