John I Gaithersburg , MD March 14, 2014 Appliance: Frigidaire Electric Range BGEF3044KFA Error Code F12 The glue behind the keypad loosened and the keypad slowly began slipping down out of place over several months. Finally, because of the movement, it warped which resulted in one of the keys being stuck. That is what gave the F12 error code. The fix was easy. I removed the control panel and then peeled off the keypad. The keypad itself then has two layers (1), the flexible circuit panel, and (2) the outward facing display. I separated the display from the circuit panel and put the new one in place. It is basically a sticker. Buttoned everything back up and it’s working perfectly. To get to the control panel. Remove the upper back panel (6 screws), unplug the panel plugs (they won’t get mixed up, they only go back in one way), and then there are 4 screws for the control panel. When you reconnect the switch pad to the control panel, you’ll need to pull up the plastic locking mechanism on the plug insert to open it. Then push it down again to lock the plug in. Of course, kill the power to the unit first! Read More... 71 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: Less than 15 minutes Tools: Nut Drivers, Pliers, Screwdrivers
Ciro I Staten Island , NY May 08, 2017 Appliance: Frigidaire Range DGGF3054KFR I had an error code of f11 it would beep and oven wouldn't turn on but all stove burners would operate I found a faulty controller and also changed the controller overlay as it would impossible to reuse the original one. Removed upper back plate (4) screws,all electrical connectors to controller and (4) controller hold down screws. Repair took total of 10 minutes start to finish. I have a Frigidaire Gallery stove/ oven Read More... 13 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: Less than 15 minutes Tools: Screwdrivers, Socket Set
Tom R St Albans , ME December 18, 2016 F11 code Installed touch-pad unit Fast delivery Unnecessary cover plate- the old one peeled off easily Read More... 13 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: 15-30 minutes Tools: Nut Drivers
Glenda J Nebo , NC July 10, 2016 F11 error on my frigidaire range replacement of eoc or overlay Diagnosed the problem with help of the internet...ordered the part and replaced it myself...and I am no repairman, just a 68 year old female... Read More... 10 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: 15-30 minutes Tools: Nut Drivers, Screwdrivers
Rob W Knoxville , TN June 21, 2021 Appliance: Frigidaire Electric Range FGEF3055KFB Frigidaire oven wouldn't reach operating temperature. Our Frigidaire oven wouldn't reach operating temperature. First, I checked to make sure there were 240 volts at the terminal block. Next I found around 16.5 ohms resistance on both the upper and lower elements. Next I found 1,090 ohms on the sensor probe at room temperature, leaving just the Oven Control Board to be the culprit. Appliance Parts Pros got me the part the next day, and it took about 30 minutes start to finish to replace, including installation of the electrical surge filter that was included in the kit. I could have used the old overlay, as it was easily removed. But my wife insisted on a new one, and it does look better. Read More... 5 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: 15-30 minutes Tools: Nut Drivers, Screwdrivers
