Product Details
Genuine Frigidaire part. Frigidaire brands include Electrolux, Frigidaire, Gibson, Kelvinator, Westinghouse, Kenmore, and others.
See all items in Freezer Relay, Overload, Capacitor and Refrigerator Relay, Overload, Capacitor.
Electrolux also makes various appliance models for Sears / Kenmore
Cross Reference Information
Part Number 5303270406 replaces AP2140817, 3204487, 3204568, 3206023, 5303288822, 623404, AH458027, EA458027, PS458027.
Description
This compressor overload is a thermal/protective device that helps prevent compressor damage by cutting power when the motor overheats or draws excessive current. It restores normal operation once conditions return to safe levels. What it does:
- Protects the refrigerator compressor from overheating and electrical overloads
- Works with the compressor start relay to help the motor start and run properly
- Common symptom linkage: replaces a failed overload when the compressor hums but won't start
- Stops compressor cycling or prevents repeated trips that cause cooling loss
What's included:
- One compressor overload (single piece as shown)
Install notes:
- Disconnect all power before replacing to avoid shock or injury
- Handle terminals carefully and reconnect matching terminal positions
- Replace only with the same part number or equivalent
- If compressor still won't start after replacing the overload, check the start relay and compressor condition.
