Frigidaire 154762601 Turbidity Sensor (Dishwasher) OEM Part

Product Details

Genuine Frigidaire part. Frigidaire brands include Electrolux, Frigidaire, Gibson, Kelvinator, Westinghouse, Kenmore, and others. See all items in Dishwasher Fuse Or Sensor.
Electrolux also makes various appliance models for Sears / Kenmore

Cross Reference Information

Part Number 154762601 replaces AP4432768, 1512449, AH2363559, EA2363559, PS2363559.

Description

This dishwasher turbidity sensor measures how dirty the wash water is and reports to the control. Replacing a faulty sensor can restore proper cycle times and cleaning performance for consistent results.

• Monitors water clarity/soil level during the wash
• Sends feedback to the control to adjust cycle length, rinses, and heating
• Failure can cause very long or very short cycles
• Can trigger sensor-related fault indications

What's included: One sensor Install notes:

• Disconnect power at the breaker and shut off water before servicing
• Access the sensor from the bottom near the sump; remove the toe panel if needed
• Unplug the wire harness; release the locking tabs or twist-lock to remove; avoid touching the optical window
• Inspect and reuse the existing seal/retainer if in good condition; seat fully and check for leaks after reassembly
