Frigidaire 241707705 Compressor Start Relay (Ptc) OEM Part

Product Details

Genuine Frigidaire part. Frigidaire brands include Electrolux, Frigidaire, Gibson, Kelvinator, Westinghouse, Kenmore, and others. See all items in Freezer Relay, Overload, Capacitor and Refrigerator Relay, Overload, Capacitor.
Electrolux also makes various appliance models for Sears / Kenmore

Cross Reference Information

Part Number 241707705 replaces AP3997558, 1259166, 216954201, AH1560523, EA1560523, PS1560523.

Description

This PTC compressor start relay briefly powers the compressor's start winding to get the motor turning, then drops out as it warms. Replacing a weak relay can restore consistent compressor starts and stabilize refrigerator and freezer temperatures.

• Momentarily energizes the compressor's start winding; disengages automatically as the PTC element heats
• Helps protect the compressor by removing the start winding after startup
• Symptoms of failure can include compressor clicking but not running
• Intermittent cooling or warming temperatures between cycles
• Heat discoloration or a burnt odor around the start device

What's included: 1 PTC start relay Installation notes:

• Disconnect power and remove the rear lower access panel
• Note wire locations; remove the start device cover/retainer and pull the old relay straight off the compressor pins
• Inspect compressor pins; firmly seat the new relay and reconnect wiring
• Reinstall covers/panels, restore power, and verify normal compressor start
