Frigidaire 316498602 Surface Element Control Switch (Infinite) OEM Part

Product Details

Genuine Frigidaire part. Frigidaire brands include Electrolux, Frigidaire, Gibson, Kelvinator, Westinghouse, Kenmore, and others. See all items in Range / Cooktop / Oven Switch.
Electrolux also makes various appliance models for Sears / Kenmore

Cross Reference Information

Part Number 316498602 replaces AP4356589, 1465936, 316498400, AH2332507, EA2332507, PS2332507.

Description

This is the variable control switch for an electric range's cooktop burner. It regulates power to the surface element so you can select steady, repeatable heat levels and restore reliable on/off control. What it does:

• Regulates voltage to a surface element based on knob position (low through high)
• Typical failure symptoms: burner won't heat, only heats on high, won't shut off, or heats inconsistently
• Can address issues when the control shaft is damaged or the switch shows signs of overheating at the terminals

What's included:

• 1 switch

Install notes:

• Disconnect power before servicing
• Access the control panel/console to reach the switch
• Note wire locations and transfer them to the new switch one at a time
• Secure the switch in the panel, reinstall knob, and test burner operation before reassembly
