Frigidaire 5304482236 Door Switch (Microswitch) OEM Part

Product Details

Genuine Frigidaire part. Frigidaire brands include Electrolux, Frigidaire, Gibson, Kelvinator, Westinghouse, Kenmore, and others. See all items in Range Hood Switch.
Electrolux also makes various appliance models for Sears / Kenmore

Cross Reference Information

Part Number 5304482236 replaces AP5272459, 2026428, AH3501128, EA3501128, PS3501128.

Description

This small door-activated microswitch signals the control that the microwave door is fully closed so cooking can start, and it opens the circuit when the door is opened. Replacing a worn switch restores reliable, safe start/stop operation. What it does:

• Detects door position and permits operation only when the door is closed
• Interrupts power when the door opens during a cycle
• Helps resolve won't-start unless pressing on the door, starts then immediately stops, or intermittent operation when opening/closing the door
• In some cases, prevent fuse or breaker trips caused by a failing interlock switch

What's included:

• 1 switch

Install notes:

• Disconnect power; if servicing a microwave, the high-voltage capacitor can retain a dangerous charge—discharge it safely before working
• Access the interlock switch bracket near the door latch; note wire positions and switch orientation
• Move one wire at a time to the new switch and ensure the actuator aligns with the door latch
• Inspect the latch and mounting bracket; replace if worn or damaged
