Frigidaire 242060202 Light/Lamp Switch (Door-Activated), 1 Switch OEM Part

Product Details

Genuine Frigidaire part. Frigidaire brands include Electrolux, Frigidaire, Gibson, Kelvinator, Westinghouse, Kenmore, and others. See all items in Refrigerator Switch.
Electrolux also makes various appliance models for Sears / Kenmore

Cross Reference Information

Part Number 242060202 replaces AP5630550, 2689381, PS3655138.

Description

This door-activated light switch installs in the refrigerator liner and opens or closes the circuit to the interior lamp as the door moves. It restores reliable, automatic on/off lighting when you open and close the door. What it does:

• Controls the interior light based on door position
• Helps fix a light that won't turn on with the door open
• Helps fix a light that stays on when the door is closed
• On some models, also signals door-ajar/dispenser interlock functions

What's included:

• 1 light/lamp switch

Install notes:

• Disconnect power to the refrigerator before servicing
• The switch is typically in the door jamb; gently release and pull it out, then transfer wires one at a time to the new switch
• Match wire positions/orientation and seat the switch flush to prevent air leaks
• Test door operation and light before finalizing reassembly

Also known as: door switch, lamp switch, switch-light/lamp
