Frigidaire 218872701 Wiring Harness (With Valve Diodes) OEM Part

Product Details

Genuine Frigidaire part. Frigidaire brands include Electrolux, Frigidaire, Gibson, Kelvinator, Westinghouse, Kenmore, and others. See all items in Refrigerator Wire, Harness, Power Cord.
Electrolux also makes various appliance models for Sears / Kenmore

Cross Reference Information

Part Number 218872701 replaces AP2115377, 452351, AH429123, EA429123, PS429123.

Description

This wiring harness routes power and signals between the appliance control and components while protecting solenoid valves with integrated diodes. It restores reliable electrical connections so controls and valves can operate correctly. What it does:

• Provides the factory wiring path between control board, valves and related components
• Integrated valve diodes suppress back-EMF from solenoid coils to protect electronics
• Restores lost or intermittent power to valves and sensors caused by damaged wiring
• Helps stop symptoms like valves not actuating, intermittent ice/water operation, or control errors tied to wiring faults

What's included: One wiring harness with preinstalled valve diodes. Install notes:

• Disconnect power before beginning work to avoid shock or component damage
• Carefully document or photograph original wire routing and connector locations for correct reassembly
• Plug connectors fully; secure harness with existing clips or ties to prevent chafing
• If terminals are corroded or connectors damaged, replace connectors rather than splicing for a reliable repair
