Elizabeth B Haverhill , MA September 20, 2020 Lower level sprayer replacement I was able to easily look up and purchase the replacement part that I needed on this site. I removed the damaged sprayer and popped in the new one. Read More... 1 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: Less than 15 minutes Tools: Screwdrivers
Kenneth D Cabot , AR November 04, 2025 Appliance: General Electric Dishwasher CDT835SSJ4SS Lower spray arm had a metal part come loose and caught on the heater elements Replaced the spray arm Read More... Do-It-Yourself Rating: Repair Time Estimate: Less than 15 minutes Tools: Nut Drivers, Pliers
Michael H Albuquerque , NM April 03, 2026 Appliance: General Electric Dishwasher PDT825SGJ5WW Lower rinse arm on dishwaher broke and melted on heater core Ordered the parts from ApplianceParts, which had the best prices and the best delivery time. I knew I needed four pieces, the arm, the housing, the clip to hold the arm and the screw to hold it all in place. Appliance parts had what I needed by serial number of the dishwasher. Parts went together pretty easily, bolted it back in place and dishwasher is back in service. Read More... Do-It-Yourself Rating: Repair Time Estimate: 15-30 minutes Tools: Nut Drivers
Paxton S Cheverly , MD January 20, 2023 The lower spray arm melted on the heating element. Used a socket wrench to unscrew the arm brace. Took the old arm off the brace and replaced it with the new one and then just screwed the brace and new arm back in Read More... Do-It-Yourself Rating: Repair Time Estimate: Less than 15 minutes Tools: Screwdrivers, Wrench Set
Erica M Herndon , VA October 05, 2026 Appliance: Model PDF820SSJ4SS GE PROFILE DISHWASHER Heat shields fell off the lower spray arm I ordered a replacement part. Once in hand, I took out the bottom dishwasher rack. There is a locking collar that holds the lower spray arm in place, however it was very hard to loosen while in the dishwasher. I watched a video on YouTube and it suggested I use a 1/4 socket wrench with an extender to remove a bolt that was holding the next piece onto the bottom of the dishwasher. Then I pushed back and up to pop it out. Turned it over, removed the locking collar, and replaced the spray arm, then replaced the unit back into the dishwasher and secured it with the socket wrench. Seems to be working perfectly now. Read More... Do-It-Yourself Rating: Repair Time Estimate: Less than 15 minutes Tools: Socket Set
