Ge WH23X10011 Drain Pump Assembly (Washer) OEM Part

Product Details

Genuine Ge part. Ge brands include General Electric, Hotpoint, RCA, Kenmore, and others. See all items in Washer Pump.
GE also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number WH23X10011 replaces AP2046377, 877781, AH271331, EA271331, PS271331.

Description

This drain pump assembly removes water from the washer tub during the drain portions of the cycle, helping ensure proper rinsing and spinning and preventing water from remaining in the machine after a wash.

• Pumps wastewater from the tub through the drain hose to the household standpipe
• Common failure symptoms include the washer not draining, water left in the tub, loud humming or grinding from the pump area, or leaks around the pump/hose connections
• Restores proper drainage to support effective spin performance

What's included: 1 drain pump assembly Installation notes:

• Disconnect power and turn off water supply before servicing; bail or wet-vac any standing water
• Keep towels or a pan handy to catch residual water when removing hoses
• Mark hose positions and transfer any existing mounting brackets or connectors from the old pump as needed
• Inspect and reseat hose clamps and the drain hose to ensure a watertight seal before testing

This part fixes the following symptoms

• Leaking
