Ge WD22X25478 Bottle Blaster Assembly (Dishwasher Bottle Jets) OEM Part

Product Details

Genuine Ge part. Ge brands include General Electric, Hotpoint, RCA, Kenmore, and others.
GE also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number WD22X25478 replaces AP6976530, WD22X25086, WD22X20190, WD22X20242, WD22X22839, WD22X25681.

Description

This bottle blaster assembly supplies targeted wash water to the dishwasher's Bottle Jets to clean tall, narrow items like baby and sports bottles. Replace a damaged or clogged assembly to restore focused spray and top-rack cleaning performance. What it does:

• Routes wash water to the bottle jet nozzles for concentrated cleaning inside bottles and narrow openings
• Helps improve cleaning on items positioned over the Bottle Jets
• Failure symptoms include no spray from the bottle jets, poor upper-rack cleaning, leaks near the jet area, or visible cracks/damage

What's included:

• 1 bottle blaster assembly

Install notes:

• Disconnect power and shut off water to the dishwasher before servicing
• Access the bottle jet area; release retaining clips/fasteners and note hose routing and connection points
• Transfer any reusable clips or seals from the original assembly if needed
• Fully seat connections; run a short cycle to check for leaks and proper jet spray
