Ge WD12X10147 Conduit (Mid-Spray) OEM Part

Product Details

Genuine Ge part. Ge brands include General Electric, Hotpoint, RCA, Kenmore, and others. See all items in Dishwasher Spray Arm & Related.
GE also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number WD12X10147 replaces AP3204820, WD12X10145, 1088511, AH958955, EA958955, PS958955.

Description

This mid-spray conduit routes wash water from the circulation system to the middle spray arm, delivering consistent coverage to the center rack. Replacing a cracked or clogged conduit can restore washing performance and help prevent leaks inside the tub.

• Directs wash water from the pump to the mid-level spray arm
• Maintains proper flow for the middle wash zone and spray arm rotation
• A damaged or obstructed conduit can cause poor cleaning on upper racks or weak/erratic spray
• Cracks, broken tabs, or loose sealing can lead to leaks from the rear of the tub

What's included: 1 mid-spray conduit Install notes:

• Disconnect power and water; wear gloves to protect hands
• Remove rack(s) as needed, release rear-wall fasteners/clips, and detach the conduit from its connections
• Align and fully seat the new conduit at all docking points until tabs lock securely
• Run a short test cycle to check for leaks and proper spray operation
