Ge WB44T10016 Bake Element (Lower Oven) OEM Part

Product Details

Genuine Ge part. Ge brands include General Electric, Hotpoint, RCA, Kenmore, and others. See all items in Range / Cooktop / Oven Heating Element.
GE also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number WB44T10016 replaces AP2031001, 876012, AH249291, EA249291, PS249291.

Description

This bake element sits at the bottom of the oven cavity and generates the heat for Bake mode, restoring steady, reliable baking performance when the original element is worn, cracked, or burned out.

• Supplies the primary heat from the bottom of the oven during Bake
• Helps the oven preheat and maintain the set temperature
• Typical failure symptoms: no heat in Bake, slow preheating, uneven baking, or visible blisters/breaks on the element
• Visual inspection may show hot spots or damage when the element has failed

What's included: 1 bake element Install notes:

• Disconnect power at the breaker or unplug the range before servicing
• Remove oven racks; take out the element's mounting screws and gently pull the element forward
• Transfer the two wires to the new element terminals one at a time; secure the element to the rear wall
• Keep wires from slipping back into the insulation; restore power and test Bake mode
