Ge WB27X27461 Electronic Oven Control Board (Erc) OEM Part

Product Details

Genuine Ge part. Ge brands include General Electric, Hotpoint, RCA, Kenmore, and others. See all items in Range / Cooktop / Oven Control Board.
GE also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number WB27X27461 replaces AP6039304, WB27T10492, 4465162, PS11771867.

Description

This electronic oven control board manages the oven's heating functions, temperature regulation, and display/clock. Replacing a failed board restores accurate temperature control and responsive controls so your oven can heat and keep time reliably.

• Controls power to bake and broil elements based on user input and sensor feedback
• Regulates oven temperature and cycle timing
• Drives the display and processes keypad/selector inputs
• Common failure symptoms: no heat, won't start, blank/unresponsive display, beeping/error codes, inaccurate oven temperature

What's included: 1 electronic control board Install notes:

• Disconnect power at the breaker before servicing
• Handle the board with ESD care; avoid touching component contacts
• Note/photograph wire positions; transfer connectors one at a time and reuse existing brackets as needed
• After reassembly, restore power, set the clock, and test bake/broil per the service sheet
