Ge WB27X27463 Electronic Oven Control Board (Erc3b2k5) OEM Part

Product Details

Genuine Ge part. Ge brands include General Electric, Hotpoint, RCA, Kenmore, and others. See all items in Range / Cooktop / Oven Control Board.
GE also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number WB27X27463 replaces AP6049805, WB27T10495, 4586271, PS12068846.

Description

This electronic oven control board manages bake/broil power, temperature regulation, and the clock/display for the range. Replacing a failed control restores accurate heating, reliable cycle timing, and responsive keypad/display operation.

• Regulates bake and broil element power using feedback from the oven temperature sensor
• Controls oven temperature, cooking cycles, and timing functions
• Operates the clock, display, and keypad interface
• Typical failure symptoms can include no heat or won't start, won't reach/hold set temperature, blank/unresponsive display, or error codes/beeping

What's included: 1 electronic control board assembly Install notes:

• Disconnect power at the breaker before servicing
• Handle the new board by the edges and use anti-static precautions
• Photograph wiring and move connectors one at a time; transfer any mounting brackets and the user interface overlay from the original
• After installation, set the clock and test bake/broil operation
