Ge WB18X31494 Harness, Burner Box Assembly OEM Part

Product Details

Genuine Ge part. Ge brands include General Electric, Hotpoint, RCA, Kenmore, and others. See all items in Range / Cooktop / Oven Wire, Harness, Power Cord.
GE also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number WB18X31494 replaces AP6890440, WB24K10056.

Description

This wiring harness assembly routes power and signals to a gas range's burner box, restoring reliable ignition and control. It replaces a damaged or burned harness to help burners and oven components receive proper electrical connections. What it does

• Delivers power and ignition signals from the main control to burner valves and igniters
• Replaces frayed or heat-damaged wiring that can cause intermittent ignition or burner failure
• Helps correct symptoms such as burners not sparking, weak ignition, or oven not heating
• Maintains factory routing and connector fit for safe, reliable operation

What's included

• One harness, burner box assembly

Install notes

• Disconnect electrical power and shut off the gas supply before starting work
• Handle wiring and connectors carefully; match connector shapes and routing to the original harness
• Secure wiring away from high-heat surfaces and moving parts during reassembly
