Ge WB24K10065 Harness, Burner Box (Wiring Harness) OEM Part

Product Details

Genuine Ge part. Ge brands include General Electric, Hotpoint, RCA, Kenmore, and others. See all items in Range / Cooktop / Oven Wire, Harness, Power Cord.
GE also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number WB24K10065 replaces AP4510150, 1567164, AH2374075, EA2374075, PS2374075.

Description

This harness connects the burner box wiring to the cooktop's controls and safety devices, ensuring reliable ignition and proper sensor/valve communication. Replaces a damaged or worn burner-box harness to restore safe burner operation. What it does:

• Carries power and signals between igniters, flame sensors/thermocouples, and gas valves
• Supports ignition; failure can cause burners to not light or spark inconsistently
• Prevents intermittent operation caused by frayed wires, loose connectors, or heat damage
• Helps maintain correct sensor feedback for safe gas shutoff

What's included:

• One burner box wiring harness

Install notes:

• Disconnect power and shut off gas supply before starting any repair
• Match connector styles and routing to the original harness; inspect nearby components for heat damage
• Use proper strain relief and secure fasteners to prevent contact with hot surfaces
