Ge WR55X10785 Dispenser Interface Assembly (Ice/Water Dispenser) OEM Part

Product Details

Genuine Ge part. Ge brands include General Electric, Hotpoint, RCA, Kenmore, and others. See all items in Refrigerator Touch Pad.
GE also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number WR55X10785 replaces AP4362835, 1477917, AH2340411, EA2340411, PS2340411.

Description

This dispenser interface assembly is the electronic control module behind the refrigerator's ice/water dispenser panel. It reads your button selections and manages the display and lights, restoring reliable dispenser control when the original interface malfunctions. What it does:

• Interprets dispenser keypad inputs (water, cubed/crushed ice, light, lock)
• Sends commands to the refrigerator to dispense ice or water as selected
• Controls the dispenser display and indicator lights
• Failure may present as unresponsive buttons, intermittent operation, or a blank/flickering dispenser display

What's included:

• 1 dispenser interface assembly

Install notes:

• Disconnect power to the refrigerator before servicing
• Carefully remove the dispenser trim/escutcheon, release locking tabs, and support wiring
• Note and unplug wire harness connectors; handle electronics with ESD precautions
• If your model uses a separate decorative overlay, transfer it from the original assembly before reassembly
