Ge WD34X11631 Keypad (Control Panel), 1 Each OEM Part

Product Details

Genuine Ge part. Ge brands include General Electric, Hotpoint, RCA, Kenmore, and others. See all items in Dishwasher Touch Pad.
GE also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number WD34X11631 replaces AP4484820, 1556706, AH2370661, EA2370661, PS2370661, WD34X11456.

Description

This keypad is the membrane-style control interface for the appliance's front control panel, restoring button responsiveness and user input. It lets you select cycles and settings without replacing the entire console. What it does:

• Replaces a worn or damaged control-panel keypad so buttons register reliably
• Common fix for unresponsive, stuck, or intermittent button behavior
• Helps restore normal user input when the display accepts commands but buttons do not
• Works with the factory control assembly to enable cycle selection and start/stop commands

What's included: One keypad (control panel membrane), 1 each Install notes:

• Disconnect power (unplug or switch off breaker) before starting work
• Remove outer console or control housing per service instructions to access the keypad
• Handle the membrane flat; avoid bending or creasing the contacts
• Reassemble carefully and verify function before finalizing repair
