Ge WD21X22277 Main Control Board Kit (Dishwasher) OEM Part

Product Details

Genuine Ge part. Ge brands include General Electric, Hotpoint, RCA, Kenmore, and others.
GE also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number WD21X22277 replaces AP6041267, WD21X20451, WD21X20721, 4466692, PS11774450, WD21X10532.

Description

This dishwasher main control board kit replaces the electronic "brain" that drives each cycle. It restores proper sequencing and reliable power to key components so wash programs run correctly when the original board has failed.

• Coordinates cycle timing and routes power to the circulation pump, drain pump, inlet valve, and heater
• Interprets signals from sensors and the user interface to start, advance, and complete cycles
• Common signs of a failing board include: dishwasher won't start or is unresponsive; stops mid-cycle or won't advance; erratic/blank display; inconsistent filling, draining, or heating

What's included: One main control board Install notes:

• Disconnect power at the breaker and shut off water before servicing
• Use ESD precautions; handle the board by its edges and avoid touching terminals
• Photograph/label connectors and transfer any model-specific jumpers or mounting hardware from the old board
• Seat all harnesses fully; restore power and run a test cycle to verify operation
