Brian M Chandler , AZ January 03, 2017 Appliance: General Electric Refrigerator HTS18GBSARWW Noisy refrigerator when fan would kick in Ordered a new Fan motor after referencing Model Number. Part was delivered in a timely matter. Unplugged Refrigerator from wall. Used a socket to remove bolts from. Cardboard access cover and also to remove Fan bracket to remove old fan and unclipped connector. Fan Blade and the two rubber grommets I reused on new replacement motor. Bolted new fan in place with Fan Blade and grommets seated. Then connected Fan connector, bolted access cover back on and plugged Refrigerator back in. Took about 8minutes total. Read More... 4 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: Less than 15 minutes Tools: Socket Set
Brian L North Las Vegas , NV July 22, 2019 Appliance: Hot Point Refrigerator HTS17CBTDRWW Frig and freezer not cold enough After removing the rear panel, I vacuumed the area. Then was easy to see condenser fan not spinning. I replaced the fan with a compression ring and a fan motor. First pulled the wiring harness connected to fan motor, then pulled off the fan with hands. Then used a wrench to remove 2 bolts for the motor. Next, pushed on new fan and screwed in the 2 bolts for the motor. Initially, I purchased a new temperature control to replace as well but after replacing fan and motor, I believe it was still functioning. The frig is 10 yrs old, so I replaced it anyway. All is working well. Read More... 4 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: 15-30 minutes Tools: Adjustable Wrench, Nut Drivers, Screwdrivers
Theodore T Sun City , AZ March 18, 2019 Needed a fan for refrigerator Very easy Read More... Do-It-Yourself Rating: Repair Time Estimate: 15-30 minutes Tools: Nut Drivers, Socket Set
Randall W Boiling Springs , PA January 01, 2024 Appliance: General Electric Refrigerator GTH18GBDDRBB Noisy evaporator fan motor and at time the condenser fan was noisy. Replaced both motors. Read More... Do-It-Yourself Rating: Repair Time Estimate: 1-2 hours Tools: Screwdrivers, Socket Set
Ira R Casa Grande , AZ January 25, 2025 Appliance: Model WR60X10238 Bad fan motor Orderered new motor from Appliance Parts, swapped out and installed to fan blade and all is well. Read More... Do-It-Yourself Rating: Repair Time Estimate: Less than 15 minutes Tools: Screwdrivers, Socket Set, Wrench Set
