Ge WR17X12494 Ice Dispenser Paddle OEM Part

Product Details

Genuine Ge part. Ge brands include General Electric, Hotpoint, RCA, Kenmore, and others. See all items in Refrigerator Lever.
GE also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number WR17X12494 replaces AP4426396, 1477338, AH2354536, EA2354536, PS2354536.

Description

The ice dispenser paddle is the front lever you press with a glass to activate ice dispensing from the freezer door. Replacing a cracked or sticking paddle restores dependable dispensing and keeps the dispenser area looking clean and finished.

• Transfers your push to the dispenser switch to start the ice dispensing cycle
• Helps ensure consistent activation when dispensing cubed or crushed ice
• Common failure signs: cracked or broken paddle, lever feels loose or sticks, must press very hard, intermittent or no ice when pressed
• Cosmetic wear at the dispenser opening

What's included: 1 ice dispenser paddle Install notes:

• Disconnect power to the refrigerator before servicing
• Remove the drip tray and carefully release the dispenser trim/control panel to access the paddle
• Remove mounting screws or tabs, note lever orientation, and transfer any reusable hardware from the old paddle
• Reassemble, restore power, and test dispenser operation
