Ge WB30T10076 Surface Element (Cooktop) OEM Part

Product Details

Genuine Ge part. Ge brands include General Electric, Hotpoint, RCA, Kenmore, and others. See all items in Range / Cooktop / Oven Heating Element.
GE also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number WB30T10076 replaces AP3426507, 911365, AH243924, EA243924, PS243924, WB30T10034.

Description

This surface element is the electric heating source for one cooktop burner. Replacing a failed element restores fast, even heat and dependable temperature control on your electric range or cooktop.

• Supplies heat to the selected surface burner when power is applied
• Restores consistent heating and proper cycling after element failure
• Common symptoms: burner won't heat, heats intermittently, or shows visible damage/hot spots
• Often tests open with a meter when failed

What's included: One surface element Install notes:

• Disconnect power at the breaker before servicing; allow the unit to cool completely
• Protect the cooktop surface; follow your service manual for access to the element
• Note wire positions; transfer wires to the same terminals and reuse existing mounting hardware
• Handle by the frame only; avoid touching the element surface. Reassemble and test operation
