Ge WB24T10167 Surface Element Rocker Switch (White) OEM Part

Worst part of job was sliding stove out from wall. Remove 4 small screws from shield on top of stove, disconnect two connectors from switch rocker, push lock tabs inward so you can push switch rocker outward from back toward burners threw frame of stove, insert new unit until click locks, reconnect wires, and reinsert shield back on top stove and secure with 4 screws removed earlier. Easy job, part shipped from AppliancePartsPros.com Fedex ASAP.

Repair was simple,remove back panel on top portion of stove,remove two wire's and push out switch.push in replacement and rewire,your done.

I ordered the part and fixed it.

Killed power, and unplugged the range. Removed 4 screws from the upper panel on the back; removed panel. Depressed the sides of the old switch and pushed it out through the front of the stove. Put the wires on the new switch and pushed it in, locking itself in position. reinstalled the upper back panel. The oven door seal was even easier. Pulled the old one off, and put the new one on, working from the top center of the door. ends just tuck into holes at the bottom of the door.
