Ge WR50X129 Defrost Thermostat OEM Part

Product Details

Genuine Ge part. Ge brands include General Electric, Hotpoint, RCA, Kenmore, and others. See all items in Refrigerator Defrost Thermostat, Sensor.
GE also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number WR50X129 replaces AP2639521, 304837, AH303478, EA303478, PS303478, WR50X0119, WR50X0127, WR50X0129, WR50X119, WR50X127.

Description

This defrost thermostat monitors the evaporator coil temperature and controls power to the defrost heater. Replacing a failed thermostat restores proper defrosting, reduces frost buildup, and helps keep fresh food and freezer compartments cooling as designed.

• Senses evaporator temperature to open/close the defrost heater circuit at the correct point in the cycle
• Protects against overheating during defrost by interrupting power when the set temperature is reached
• Helps prevent heavy frost/ice accumulation on the evaporator and loss of airflow
• Common signs it may be bad: ice behind the freezer rear panel, warm refrigerator section, unit never defrosts or refreezes soon after a manual defrost

What's included: 1 defrost thermostat Installation notes:

• Disconnect power before servicing; wear cut-resistant gloves
• Remove the freezer's rear panel to access the evaporator; the thermostat is typically clamped to an evaporator tube
• Match wire positions and mount the new thermostat in the same location with firm contact to the tubing
• Route wires away from the fan and sharp edges; reassemble and verify normal defrost operation
