Ge WH12X10196 Timer Assembly (Washer Control) OEM Part

Product Details

Genuine Ge part. Ge brands include General Electric, Hotpoint, RCA, Kenmore, and others. See all items in Washer Control Board.
GE also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number WH12X10196 replaces AP3190897, 947871, AH269928, EA269928, PS269928.

Description

This timer assembly controls the wash cycle sequence and timing so the machine advances through fill, agitate, drain and spin steps. Replaces a worn or non-advancing control to restore proper cycle sequencing. What it does:

• Selects and advances washer cycles (fill, agitate, drain, spin) based on timer position
• Restores cycle advancement when the dial won't move or the washer is stuck on one cycle
• Stops erratic or intermittent cycle changes caused by a failing timer
• Works with mechanical timer-driven cycle controls

What's included:

• One timer assembly

Install notes:

• Disconnect power before starting; this part requires handling internal controls
• Remove the control panel or console to access and replace the timer; retain alignment of the dial and actuator
• Note and reconnect all wiring to the same terminals; avoid forcing connectors
• After installation, test multiple cycles to ensure proper advancement
