Ge WH12X10337 Timer Assembly (Washer) OEM Part

Product Details

Genuine Ge part. Ge brands include General Electric, Hotpoint, RCA, Kenmore, and others. See all items in Washer Control Board.
GE also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number WH12X10337 replaces AP3995256, 1264489, AH1482374, EA1482374, PS1482374.

Description

The Washer Timer controls the sequence and duration of wash, rinse, and spin cycles. Replacing a worn timer restores proper cycle progression so the washer starts, advances, and completes loads reliably without manual knob turning.

• Sends power to water inlet valves, drive motor, and drain pump at the correct times
• Advances the wash, rinse, and spin stages in order
• Failure symptoms include: won't start, won't advance or stops mid-cycle, runs only on one setting, or no agitate/spin
• Helps restore accurate cycle timing and completion

What's included: 1 washer timer assembly Install notes:

• Disconnect power before servicing
• Open the console/control panel to access the timer; remove mounting screws/clips
• Label or photograph wire locations and transfer wires to the new timer one at a time
• Reuse the existing knob and dial as needed; seat the shaft fully and test a short cycle
