Daniel H Deridder , LA June 12, 2021 Appliance: Hot Point Washer HSWP1000M4WW The timer washer knob would not turn the dial assembly. I replaced the Timer knob components. Removing the cover that contains the Timer was simpler than I anticipated. Just remove the screws on the top of the back of the machine. Hold the cover and lift up and push to the left (facing the front of the washer). Removed the Timer Knob Clip with small needle-nose pliers. Grasped the Timer and turned counterclockwise to remove and unplugged the wiring clip. The timer is seated to the cover and held securely in place with one screw. I seated the new Timer into the inside of the cover. This step took a minute to figure out but if you look at the inside of the cover, and then the back of the Timer, it is easy to see how it fits. Replaced the single screw that holds the Timer in place. Replace the wiring (one clip with many wires that simply snaps into place). Reseated the cover and replaced the screws. I've never done this task before and I figured it out by looking at it. Much simpler than I thought. The difficulties? 1. Removing the cover. It doesn't just lift up. You must lift up and slide it over. 2. Removing the Timer mechanism. Once the screw is removed, the Timer must be twisted to be removed. Once you take it off, you will know how to put the new one back on. Read More... 6 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: 15-30 minutes Tools: Nut Drivers, Pliers
Bonnie A Saranac , NY July 08, 2018 Did not spin out New timer Read More... 3 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: Less than 15 minutes
Richard M Richmond , KY April 19, 2021 Timer on washer. Installed timer only took 15 minutes. Read More... 2 People found this story helpful Do-It-Yourself Rating: Repair Time Estimate: 15-30 minutes Tools: Screwdrivers, Wrench Set
Allen P Worcester , MA October 09, 2024 Timer stopped before one of the cycles finished Put in a new timer. Easy to do works perfectly. Read More... Do-It-Yourself Rating: Repair Time Estimate: Less than 15 minutes Tools: Nut Drivers, Pliers, Screwdrivers
Cindy S St Clairsvle , OH January 16, 2026 Appliance: General Electric Washer GTWN2800D2WW Washer water level quit working wouldn’t agitate stopped spinning would run a cycle with the lid open without tub moving wouldn’t turn off weird noise sounding like the drum was off balance Replaced the washer timer. Everything is working correctly again. Read More... Do-It-Yourself Rating: Repair Time Estimate: Less than 15 minutes Tools: Screwdrivers
